New High-speed and High-sensitivity Linea HS TDI Camera
Posted:
Teledyne DALSA, a Teledyne Technologies company and global leader in machine vision technology, is pleased to announce that its newest charge-domain CMOS TDI camera–the Linea HS─is in volume production. Based on a multi-array TDI sensor architecture, the 16k camera offers 300 kHz line rate or 5 GPix/sec data throughput for high-performance imaging applications such as flat panel display, PCB and wafer inspection, gene sequencing, digital pathology, and web inspection.

The Linea HS family offers versatile capabilities for monochrome/HDR, multifield™, and super resolution imaging in light-starved conditions. For the monochrome model, the sensor has two arrays. The main array has 128 stages, while the secondary array has 64 stages. The sensor offers the best detectability, with a much lower noise equivalent exposure, and improved MTF when compared with existing CCD TDI devices. New features such as active pixel-assisted alignment helps end-users to precisely align samples under inspection.

"Multi-array TDI technology provides cutting-edge performance for today’s demanding vision applications. Various selectable stage combinations of both arrays enable best imaging results to meet different application requirements," said Xing-Fei He, Senior Product Manager.

Combined with the Xtium™2 CLHS series of high-performance frame grabbers from Teledyne DALSA, these new products represent a breakthrough in data throughput in the industry. Built on field-proven technology, the next generation CLHS fiber optic interface provides reliable and high throughput data transmission. Fiber optic cables lower system costs, offer longer cable lengths (up to 300 m), are immune to electromagnetic radiation, and are ideal for industrial environments. Teledyne DALSA’s Xtium2 family of high-performance frame grabbers feature the PCI Express Gen 3 x8 platform.

Key Features:

High speed of up to 300 kHz line rate in 16k/8k resolutions, or 5 Gpix/sec
Mono/HDR imaging with single or dual outputs
Very low noise and high sensitivity
Active pixel assisted alignment
Camera Link HS fiber optic interface for high reliability and long cable data transmission
Lower system costs
Please visit the Linea HS product page for more information. For sales enquiries, visit our contact page, and for full resolution images, our online media kit.

About Teledyne DALSA’s Machine Vision Products and Services
Teledyne DALSA is a part of the Teledyne Imaging group and a leader in the design, manufacture and deployment of digital imaging components for machine vision. Teledyne DALSA image sensors, cameras, smart cameras, frame grabbers, software, and vision solutions are at the heart of thousands of inspection systems around the world and across multiple industries. For more information, visit www.teledynedalsa.com/imaging.

Teledyne Imaging is a group of leading edge companies aligned under the Teledyne umbrella. Teledyne Imaging forms an unrivalled collective of expertise across the spectrum with decades of experience. Individually, each company offers best-in-class solutions. Together, they combine and leverage each other’s strengths to provide the deepest, widest imaging and related technology portfolio in the world. From aerospace through industrial inspection, scientific research, spectroscopy, radiography and radiotherapy, geospatial surveying, and advanced MEMS and semiconductor solutions, Teledyne Imaging offers worldwide customer support and the technical expertise to handle the toughest tasks. Their tools, technologies, and vision solutions are built to deliver to their customers a unique and competitive advantage.
